Положительные характеристики: High efficiency and energy conservation; duct-type structure for easy installation; electromechanical integration; small occupying area; wide application scope; easy-disassembly structure; convenient and speedy maintenance.
Области применения: For transporting oils like diesel oil and gasoline etc., as well as other flammable and explosive mediums.
Технические параметры:
Flow Rate Q: 2~1400m3/h
Delivery Lift H: 5~135m
Rotary Speed N: 980~2900 r/min
Caliber: Ф 15~Ф350
Temp. Range T: －15~＋120℃
Service Pressure P: Max. 1.6 Mpa
Material: cast iron, stainless steel, cast steel.
